Damping & Safety Toggle Latch

A125

Damping & Safety Toggle Latch

application：Vehicle engine hood /machine hood/oscillatory machine

catalogue CAD data

Product size diagram

Product size and properties

Model Number	Function	Length（mm）	Material	Weight (g)	Locking Force（N）	Ultimate Load（N）	3D DRAWINGS
A125	Damping	243	Elastomer	129	200	250
A125B	Damping	243	Elastomer	130	200	250

characteristic

Latch body made of high quality rubber to reduce viberation & apply prepressing

Available services

Statement: The "Locking Force" in the chart is the best locking force determined by the test (meaning that adults can easily open and close with bare hands); the hole distance between the hook and the latch body in the picture is the unstressed dimension, which needs to be adjusted hole spacing by yourself to meet different locking force requirements.

Product Name
Damping & Safety Toggle Latch

More information

If you have more technical advice，Please call
0535-6217008-801
