Product size diagram
Product size and properties
| Model Number | Weight（kg）  | Orientation Angle | Max Attraction（kg） | Dimensions（mm） | Width of jaw（mm） | Opening length（mm） | Clamping height（mm） | Max Clampping Force（kg） | Length（mm） | Throat deepth（mm） | Clamping Force（kg） | The guide rail section（mm） | Sliding rail（mm） | Location hole（mm） |
3D DRAWINGS |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| CLA-30 | 0.09 | 30/60*45*90 | 10 | 65*55*12 | / | / | / | / | / | / | / | / | / | / | |
| CLA-30H | 0.145 | 30/60*45*90 | 15 | 60*55*16 | / | / | / | / | / | / | / | / | / | / | |
| CLA-45 | 0.50 | 45*90 | 30 | 108*111*24 | / | / | / | / | / | / | / | / | / | / | |
| CLA-45H | 0.726 | 45*90 | 40 | 108*111*24 | / | / | / | / | / | / | / | / | / | / | |
| CLA-46 | 0.46 | 30/60*45*90 | 30 | 108*111*24 | / | / | / | / | / | / | / | / | / | / | |
| CLA-46H | 0.71 | 30/60*45*90 | 40 | 108*111*24 | / | / | / | / | / | / | / | / | / | / |
characteristic
Micro magnetic welding fixer can clamp parts in small space
Available services
Ideal for steel plate,circular and square tube, angle iron.
Product Name
No-Switch Magnetic Welding Fixer
No-Switch Magnetic Welding Fixer
