| model | material quality | Diameter D | M | S | H | h | Weight (g) | Static load (KN) | 3D |
| R10-50-M8-35 | carbon steel | 32 | m8 | 35 | 63 | 20 | 1 | 1 | Download |
| R10-50-M8-50 | carbon steel | 32 | m8 | 50 | 78 | 20 | 1 | 1 | Download |
| R10-50-M8-75 | carbon steel | 40 | m8 | 75 | 103 | 20 | 1 | 1 | Download |
| R10B-50-M8-35 | sus304 | 40 | m8 | 35 | 63 | 20 | 1 | 1 | Download |
| R10B-50-M8-50 | sus304 | 50 | m8 | 75 | 78 | 20 | 57.51 | 1 | Download |
| R10B-50-M8-75 | sus304 | 50 | m8 | 75 | 103 | 20 | 70.01 | 1 | Download |
material quality-Disc seat:PA super tough nylon
material quality-Screw:SUS 304Stainless steel
material quality-Disc gasket: Rubber (NBR), oil resistant, alkali resistant, and heat-resistant to 130 ℃.
Extremely smooth screw, quick installation.
The screw provides a 15 degree universal adjustment to eliminate angle tolerances and improve machine alignment stability.
